Introduction of Ceramic Hybrid HF PCB
Rogers RO3003 PCB high frequency circuit materials are PTFE composite ceramic fillers for commercial microwave and RF applications. This family of products provides exceptional electrical and mechanical stability at a competitive price.
Technical parameters of Ceramic Hybrid HF PCB
Model:RO3003 Ceramic Hybrid High Frequency PBB
Material: Rogers RO3003+FR4 Mixed dielectric
Layer: 6L
D K:3.00±0.04
Finished Thickness: 2.0MM
Copper Thickness:10Z
Dielectric Thickness:0.762mm
Thermal Conductivity: 0.43w/m.k
Flammability: 94V-0
Surface Treatment Immersion Gold
Application: Guided wave radar level gauge(GWRLG)PCB
RO3003 has excellent stability of dielectric constant with temperature, eliminating the jump in dielectric constant of PTFE glass cloth material near room temperature. In addition, RO3003 laminates exhibit an extremely low dielectric loss of 0.0013 at 10 GHz.
Product Applications: Automotive radar, RF couplers, aerospace and defense applications.
