Introduction of Cavity PCB
The cavity PCB is used for the power divider; the main technical parameters of the power divider include power loss, voltage VSWR of each port, isolation between distribution ports, power capacity and bandwidth, etc.
Technical parameters of Cavity PCB
Product Name:Cavity PCB
Material: Teflon F4MB
Quality standard:IPC6012 Class 2
Dielectric constant:2.55
Layers: 2Layers
Thickness: 1.5mm
Copper thickness: base copper 0.5ozfinished copper thickness 1oz
Surface technology: Immersion Silver
Application: Cavity PCB for power divider
