Introduction of Teflon PCB
Teflon PCB in high-end electronic products are made of Teflon laminate material, which is resistant to acids and bases and various organic solvents, and is insoluble in almost all solvents. At the same time, Teflon material has the property of high temperature resistance and its dielectric coefficient is very low, which is the ideal high frequency PCB material for high frequency Teflon PCB.
Technical parameters of Teflon PCB
Product Name:Teflon PCB
Material: Teflon laminate material
Quality standard: IPC6012 Class I or Class III
Dielectric constant:2.0-3.5
Layers: 2 layer- 34 layer
Thickness:0.1mm-12mm
Copper thickness: base copper 0.5oz.finished copper thickness 1oz
Surface technology: Immersion Gold,ISIG
Special requirements: high precision of RF line
There are requirements for DK and DF of materials
Application: Microwave high-frequency PCB application
Excellent performance of Teflon PCB
- High-temperature resistance:long-term use temperature 200~260 degrees.
- Low-temperature resistance: still soft at-100 degrees.
- Corrosion resistance: can withstand aqua regia and all organic solvents.
- Weather resistance: the best aging life among plastics.
- High lubrication: has the smallest coefficient of friction in plastics(0.04).
- Non-sticky: It has the smallest surface tension among solid materials without adhering to any substance.
- It is physiologically inert; it has excellent electrical properties and is an ideal C-level insulating material.A thick layer of newspaper can block the high voltage of 1500V it is smoother than ice.
Scope of application of Teflon PCB
1.Related to lighting and communication systems.
2.Power amplifier, low noise amplifier, etc.
3.Passive components such as power splitters,couplers,duplexers,filters, etc.
4.In the fields of automobile anti-collision systems, satellite systems, and radio systems, high-frequency electronic equipment is a development trend.
In general, high frequency Teflon PCB has the characteristics of high income, high reception signal, wide range, low noise factor and high stability, as well as Teflon material has the advantages of high temperature resistance, corrosion resistance, non-stick, self-lubrication, excellent dielectric properties, very low friction coefficient, etc., very suitable for applications in the field of radar, high frequency communication equipment, radio equipment; and with the increase in power signal frequency, the The loss of the sheet is very small, the importance of high frequency Teflon PCB is becoming more and more prominent.
