Introduction of Component Substrate PCB
Component Substrate PCB selection of the substrate material should first consider the electrical characteristics of the substrate material, that is, the insulation resistance of the substrate, arc resistance and breakdown strength; secondly, to consider its mechanical properties, that is, the shear strength and hardness of the printed circuit board.
Technical parameters of Component Substrate PCB
Model:Component Substrate PCB
Material:CC-HL820WDI
Layers: 2layers
Thickness: 0.3mm
Resistance welding: PSR-4000 WT03
Surface treatment:Hard Gold
Minimum aperture:0.25mm
Minimum line distance:75um
Minimum line width: 75um
Application: Electronic components Substrate
The package substrate is an important part of the electronic package and serves as a bridge between the chip and the external circuitry. The substrate plays the following roles in the package:
1.To realize the transmission of current and signal between the chip and the outside world;
2.Mechanical protection and support for the chip;
3. It is the main way for the chip to dissipate heat to the outside world;
4. s the space transition between the chip and the external circuit.
