4-Layer DDR Substrate

High density structure: hole-filling plating and stacked hole structure

Send Inquiry

Appendix

Product Description

Technical parameters of 4-Layer DDR Substrate

Product Name: 4-lavers DDR Substrate Board

Material:Mitsubishi Gas Chemical HL832

Layers: 4L

Thickness: 0.25mm

Copper thickness:0.5oz

Color: Green(AUS308)

Surface treatment: Soft Gold

Minimum aperture:100um

Minimum line distance:75um

Minimum line width:50um

Application: IC substrate board

Features of DDR package carrier

1.High density structure: hole-filling plating and stacked hole structure

2.A variety of surface treatment methods

3.Sheet and surface flatness requirements

4.Resin filling

5.DDR packaging carrier application process: semi-additive method, laser punching

6.DDR packaging carrier applications: smart phones, computers, Internet of Things products, SMS electronic products
