Introduction of Rigid-Flex PCBA
Rigid-Flex PCBA designs are more challenging than typical designs for rigid board environments because these boards are designed in 3D space, which also provides greater space efficiency.
Technical parameters of Rigid-Flex PCBA：
Name：Rigid-Flex PCBA design and manufacturing
Reinforcing material:glass fiber cloth base
Insulating resin: polyimide resin (Pl)
Product thickness: soft plate 0.15mm
Hardboard 0.5mm;(tolerance+0.03mm
Single-chip size: it can be customized according to customer supplied drawings
Copper foil thickness: 18 u m(0.5oz)
Solder resist film / oil: yellow film/black film/white film/ green oil
Coating and thickness:OSP(12um-36um)
Fire rating: 94-V0
Temperature resistance test thermal shock288 10sec
Advantages of Rigid-Flex PCBA
1.Effectively save PCB space and eliminate the process of using connectors or shortcut bars.
2.Shorten the signal transmission distance of Rigid-Flex PCBA, increase the speed, which can effectively improve the reliability.
3.Rigid-flexible combination PCBA simplifies product assembly and saves assembly man-hours.
4.Rigid-flexible combination PCBA provides a wide range of applications from smart devices to cell phones and digital cameras, and can be applied to intelligent control systems.
5.In consumer products, rigid-flexible PCBA maximizes space and reduces weight, and also improves reliability.
