Introduction of LED Ceramic PCB
Unlike traditional FR-4 or aluminum substrates, Ceramic based PCB have a coefficient of thermal expansion close to that of semiconductors and high heat resistance, making them suitable for high thermal value products (high brightness LED, solar energy) and their excellent weather resistance is more suitable for harsh outdoor environments.
Technical parameters of LED Ceramic PCB
Model:LED Ceramic PCB.Ceramic Substrate PCB
Material:Ceramic Substrate
Layer:2Layer Ceramic PCB
Color:White
Thickness:Aluminum nitride 0.635mm
Copper Thickness:10Z(35um)
Surface Treatment:Immersion Gold
Gold thick : >=3U"
Minimum aperture:0.8mm
Application:high power LED PCB,LED lamp PCB,LED street lamp PCB,solar energy inverter PCB
Features of ceramic substrate PCB
-Structure: excellent mechanical strength, small warpage, thermal expansion coefficient close to silicon (aluminum nitride), high hardness, good processability, high dimensional accuracy
-Climate: suitable for high temperature and high humidity environment, high thermal conductivity, good heat resistance, corrosion and wear resistance, UV resistance, anti-yellowing
-Chemical: lead-free, non-toxic, good chemical stability
-Electrical performance: high insulation resistance, easy metallization, strong adhesion of circuit graphics to it
-Market:abundant materials (clay, aluminum), easy to manufacture, low price
