Introduction of Heavy Copper PCB
Thick copper PCB is suitable for strong electrical connections, imparting, and mixed connections of components. With the widespread use of PCB in automotive electronics and power communication modules, the functional requirements of thick copper PCB is increasing: PCB not only need to provide the necessary electrical connections and mechanical support for electronic components, but also need to be able to integrate power supplies, provide high currents and high reliability.
Technical parameters of Heavy Copper PCB
Model: Heavy Copper PCB
PCB Material:SYS1141
PCB Layer: 6Layers
Solder mask Color:Green
Silk Screen:White
Copper thickness:20Z/6OZ(70um
Board Thickness: 2.8mmmm
Surface technology: Immersion Gold(1-3U)
Application: Power converter Heavy Copper PCB
