Technical parameters of FPGA multi-data acquisition card PCBA
Name：FPGA multi data acquisition card PCBA
Layers: 12Layers
Surface Process:Immersion Gold
Gold thickness:2U
PCB Color: Green solder mask
PCB Testing:Yes
PCBA Testing:Yes
Provide PCB Manufacturing:Yes
SSPCB company provide full electronic components.
PCBA Testing: Yes(Customer provide testing step with video)
RoHS compliant lead-free assembly
Advantages of FPGA multi-data acquisition card PCBA
1.FPGA has unparalleled advantages in high-speed data acquisition between DSP and MCU because of its high clock frequency, small internal delay, fast speed, high efficiency and flexible composition.
2. The data acquisition system of FPGA multi-data acquisition card adopts modular design structure and consists of four modules, each acquisition module can be interchanged or flexibly increased. The modules are connected through a three-way connection to the master. Sensor signals and 422 serial signals are input to the corresponding modules, and the master control module controls the unified framed transmission to the dual backup memory. The design scheme is flexible, easy to dry control and has good practical value.
