Introduction of FPC Flexible PCB
FPC is also known as Flexible PCB, FPC is made of PI or PET flexible PCB raw material, which can be folded and bent.FPC is a kind of flexible circuit board with high line density, light weight, thin thickness and good bending performance.
Technical parameters of FPC Flexible PCB
Model: FPC Flexible PCB
Material: PI.PET
Layers: 1 layer-12 layers
Finished Thickness:0.1mm+0.8mm
Copper Thickness: 1/3OZ-10Z
Color:Yellow/Green/White
Surface Treatment:Immersion Gold/OSP
Min Trace/Space:2mil/2mil
Min Hole: 0.1mm
Application: Various electronic products
Characteristics of FPC Flexible PCB
Currently, there are four types of FPC flexible PCB: single-sided, double-sided, multilayer and Flex-Rigid PCB.
1.Single-sided FPC flexible PCB in the electrical performance requirements are not high when the lowest cost.
2.Double-sided FPC flexible PCB is etched on each side of the insulating base film a layer of conductive graphics, metalized holes will lend the graphics on both sides of the raw material to form a conductive path to meet the flexible design and functional role.
3.Multilayer FPC flexible PCB is formed by drilling Ls and plating the metallization holes to form a conductive path between the layers, which eliminates the need for complex welding processes, and multilayer circuits have higher reliability, better thermal conductivity and more convenient assembly performance.
4.Mixed structure of the FPC flexible PCB is a multilayer PCB circuit board, conductive layer consists of different metals, leads from the main board of three different directions, this hybrid structure is mostly used for electrical signal conversion and thermal conversion relationship and electrical performance requirements of higher low-temperature environment.
