Introduction of DPC ceramic substrate
DPC ceramic substrate features: high thermal conductivity, high insulation, high circuit resolution, high surface flatness, and high metal-ceramic bonding.
Technical parameters of DPC ceramic substrate
Model:DPC ceramic substrate
Material:Ceramic aluminium oxide
Layer: 2Layers
Color:White
Finished Thickness:2.4mm
Outer copper thickness:20Z
Surface Treatment:Hard Gold
Special process: PCB ceramic bracket
Application:LED substrate PCB
DPC (Direct Plate Copper) ceramic substrate, also known as direct copper plated ceramic substrate, is a new type of ceramic substrate that combines thin film circuit and plating process technologies. It is used not only for conventional lighting such as stage, landscape and automotive headlights, but also for packaging high-power components such as vertical cavity surface emitting lasers (VCSELs), and also ultraviolet light emitting diodes (UVLEDs) and other fields. In short, DPC ceramic substrates that combine the advantages of ceramic processing and material processes will have many features such as high thermal conductivity, high insulation, high circuit accuracy, high surface flatness, and thermal expansion coefficients that match the chip.
