Technical parameters of 4-layer PCB for Bluetooth
Model:4lavers Multilayer Bluetooth PCB
Material:FR4
Layer: 2Layers
Color:Black/White
Finished Thickness:1.0mm
Copper Thickness:10Z
Surface Treatment:Immersion Gold
Min Trace:4mil(0.1mm)
Min Space:4mil(0.1mm)
characteristic: Half hole PCB
Application: Multilayer Bluetooth PCB
SSPCB is a high-tech enterprise focusing on high-end PCB development and production, we have our own production factory and R&D team to provide professional PCB technology and production services to our customers.
Surface treatment:OSP/ENIG/HASLLF/gold plating/flash gold/submerged tin/submerged silver/electrolytic gold
Capacity:Gold finger/heavy copper/blind buried hole/impedance control/filling resion/carbon ink/back drilling/buried hole/deep drilling/semi-plated hole/press fit hole/peelable blue mask/peelable soldermask/thick copper/oversized
Material:RogersRO4350B/RO3003/RO4003/R3006/RT/Duroid5880/RT5870 and Arlon/Isola/Taconic/PTFE F4BM/Teflon material etc.
Number of layers:2L 4L 6L 8L 10L 12L 14L 16L 18L 20L 22L 24L 26L 28L 30L
Dielectric constant(DK): 2.20/2.55/3.00 /3.38 / 3.48 / 3.50 / 3.6 / 6.15 / 10.2
Applications: Consumer Electronics / Library / Space / Antennas and Communication Systems / High Power / Medical / Automotive / Industrial / Handheld Cellular / WiFi Antennas / Telematics and Infotainment / WiFi / Computing / Radar / Power Amplifiers.
